- Superior video quality – HDTV resolutions of 480i, 480p, 720i, 720p, 1080i, 1080p (1920 x 1080); VGA, SVGA, XGA, SXGA, UXGA and WUXGA (1920 x 1200)
- EDID Wizard – allows a user an easy way to manage EDID settings
- EDID mode selection – Default, Learning , Programming
- Automatically manages EDID communication between connected devices
- Signaling rates up to 2.25 Gbits in support of 1080p display
- LED indication of video source devices
- Supports wide screen
- Supports hot-plugging
-
Non-Powered *
* If the video source is not receiving enough power an external power cord should be connected.
| Video Input | |
| Interfaces | 1 x DVI-I Female (White) |
| Impedance | 100 Ώ |
| Video Output | |
| Interfaces | 1 x DVI-I Female (White) |
| Impedance | 100 Ώ |
| EDID Settings | EDID Mode: Default / Learn / Customized (EDID Wizard support) |
| Connectors | |
| Power | 1 x DC Jack |
| Power Consumption | DC5V:0.13W:1BTU |
| Environmental | |
| Operating Temperature | 0 - 50 ºC |
| Storage Temperature | -20 - 60 ºC |
| Humidity | 0 - 80% RH, Non-Condensing |
| Physical Properties | |
| Housing | Metal |
| Weight | 0.15 kg ( 0.33 lb ) |
| Dimensions (L x W x H) |
7.90 x 7.86 x 2.45 cm (3.11 x 3.09 x 0.96 in.) |
